C9300-24UX-A Cisco Catalyst 9300 Series 24-Port UPOE Switch | Network Advantage

BRAND NEW. FACTORY SEALED. RETAIL BOXED. FULL CISCO WARRANTY INCLUDED.
SUPPLIED BY CHICAGO COMPUTER SUPPLY

Overview

The C9300-24UX-A is a high-performance Cisco Catalyst 9300 Series access switch built for enterprise environments that demand advanced power delivery, multigigabit connectivity, and full Layer 3 intelligence. With 24 UPOE-capable ports supporting speeds up to 10G, this switch powers and connects Wi-Fi 6 access points, collaboration endpoints, cameras, and high-density IoT devices.

Powered by the Network Advantage software edition, the C9300-24UX-A delivers advanced routing, segmentation, and policy-based control at scale. Its architecture supports secure, software-defined campus networks while ensuring long-term performance, resiliency, and operational consistency.

Key Features

• 24 multigigabit UPOE ports supporting up to 10G speeds
• Network Advantage software with advanced Layer 3 capabilities
• High PoE budget for power-intensive enterprise endpoints
• Stackable design for scalable campus deployments
• Built for secure, software-defined access networks

Technical Specifications

General

• Manufacturer: Cisco
• Product Line: Cisco Catalyst
• Product Series: 9300
• Model: C9300-24UX-A
• Software Edition: Network Advantage
• Product Type: Managed Layer 3 Switch
• Form Factor: Rack-mountable

Ports & Interfaces

• 24 × 100/1000/2.5G/5G/10GBase-T RJ-45 UPOE ports
• 1 × USB 2.0 port

Performance & Capacity

• Switching capacity: 640 Gbps
• Stacking bandwidth: 480 Gbps
• Forwarding rate: up to 400 Mpps
• VLAN IDs: up to 4,000
• SVIs: up to 2,000
• IPv4 routes: up to 32,000
• IPv6 routes: up to 16,000
• Flexible NetFlow entries: up to 128,000

Management & Security

• Managed via CLI, NETCONF, RESTCONF, SNMP
• Jumbo frame support up to 9,198 bytes

Power & Physical

• PoE type: UPOE
• PoE budget: 830 W
• Internal power supply with optional redundancy
• Dimensions: 17.5" W × 20.2" D × 1.7" H
• Weight: 18.19 lbs

UPC: 00889728051644

Use Cases

The C9300-24UX-A is ideal for enterprise access layers supporting multigigabit Wi-Fi 6 deployments, unified communications, smart building systems, and high-density IoT environments. It fits organizations that require advanced routing, high power availability, and consistent policy enforcement across large campus or branch networks.

Why Choose the C9300-24UX-A

• Delivers advanced Layer 3 routing with Network Advantage
• Supports high-power UPOE devices without external injectors
• Scales easily within Catalyst 9300 campus architectures
• Designed for secure, software-defined enterprise networks
• Ships brand new with full Cisco manufacturer warranty

FAQs

Which ports does the C9300-24UX-A offer?

It includes 24 multigigabit UPOE ports supporting speeds up to 10G.

Is this switch suitable for Wi-Fi 6 access points?

Yes. It is for high-density wireless and multigigabit endpoints.

Does the C9300-24UX-A support stacking?

Yes. It supports stackable deployments for scalability and resiliency.

What software license do we get?

The switch ships with the Network Advantage software edition.

Is this product new and under warranty?

Yes. It is brand new, factory-sealed, and covered by the full Cisco manufacturer's warranty.
