Cisco 1000Base-LX/LH GBIC Transceiver Module WS-G5486

CISCO GENUINE. BRAND NEW. FACTORY SEALED. RETAIL BOXED. FULL CISCO LIMITED LIFETIME WARRANTY. FROM CHICAGO COMPUTER SUPPLY

Overview

Some networks still rely on proven GBIC-based infrastructure, especially in enterprise switching environments where stability matters more than constant hardware refresh. The Cisco WS-G5486 GBIC keeps networks running smoothly with reliable Gigabit Ethernet fiber connectivity.

This hot-swappable transceiver supports 1000Base-LX/LH and operates at 1300nm, making it ideal for both multimode and single-mode fiber deployments. It supports up to 10 km on single-mode fiber (SMF) and up to 550 m on multimode fiber (MMF), depending on the cabling type and modal bandwidth.

If you want long-haul fiber reach with a trusted Cisco GBIC form factor, this module delivers clean performance and enterprise-grade reliability.

Key Features

• Supports Gigabit Ethernet 1000Base-LX/LH fiber connectivity
• Hot-swappable GBIC transceiver for easy installation and replacement
• Operates at 1300nm wavelength for stable long-wavelength transmission
• Supports up to 10 km on single-mode fiber (SMF)
• Supports up to 550 meters on multimode fiber (MMF)
• Uses dual SC connectors for common GBIC fiber setups
• Designed for Cisco Catalyst and enterprise networking environments
• Fully compliant with IEEE 802.3z 1000Base-LX standards
• Backed by Cisco's limited lifetime warranty when purchased new

Technical Specifications

Description: Cisco 1000Base-LX/LH GBIC Transceiver Module WS-G5486
Manufacturer: Cisco
Model / Part Number: WS-G5486 / WS-G5486=
Device Type: GBIC Transceiver Module
Network Standard: 1000Base-LX/LH (Gigabit Ethernet)
Compliant Standard: IEEE 802.3z
Wavelength: 1300 nm
Connector Type: Dual SC
Fiber Type Supported: MMF and SMF

Distance Support (Typical):
MMF (62.5µm, 500 MHz/km): Up to 550 m (1804 ft)
MMF (50µm, 400 MHz/km): Up to 550 m (1804 ft)
MMF (50µm, 500 MHz/km): Up to 550 m (1804 ft)
SMF (9/10µm): Up to 10,000 m (32,810 ft)

Cisco Part Number: WS-G5486=
UPC (Reference): 00746320109794, 00746320110738, 07463201107382

Use Cases

The Cisco WS-G5486 is ideal for organizations maintaining Cisco Catalyst switching environments that still use GBIC transceivers. It works well for backbone links, distribution-layer uplinks, wiring closet fiber runs, and campus connectivity where long-wavelength Gigabit Ethernet is required. If your infrastructure needs flexibility across both multimode and single-mode fiber, this GBIC offers a stable, practical solution.

Why Choose the WS-G5486

• Reliable Cisco GBIC for Gigabit Ethernet fiber connectivity
• Supports both SMF long reach and MMF short reach deployments
• Up to 10 km on SMF, ideal for building-to-building and campus links
• Uses dual SC connectors, common in legacy fiber networks
• Hot-swappable design makes maintenance quick and efficient
• Strong fit for Cisco Catalyst networks using the GBIC form factor
• Cisco genuine optic supplied new and factory sealed
• Includes Cisco's limited lifetime warranty for long-term confidence

FAQs

What is the Cisco WS-G5486 used for?

The Cisco WS-G5486 is a GBIC transceiver module that provides 1000Base-LX/LH Gigabit Ethernet fibre connectivity. It connects Gigabit Ethernet ports to fiber networks in Cisco switching environments.

What fiber types does the WS-G5486 support?

It supports both single-mode fiber (SMF) and multimode fiber (MMF). It makes it flexible for mixed enterprise cabling environments.

What is the maximum distance supported on single-mode fiber?

On single-mode fiber, the WS-G5486 supports distances up to 10 km. Actual reach depends on fiber quality and installation conditions.

What is the maximum distance supported on multimode fiber?

Multimode fiber supports up to 550 meters, depending on the fiber core size and the modal bandwidth rating.

What wavelength does the Cisco WS-G5486 operate on?

The WS-G5486 operates at 1300nm, a wavelength commonly used for long-wavelength Gigabit Ethernet transmission over fiber.

What connector type does the WS-G5486 use?

This GBIC uses two SC connectors, making it suitable for legacy fiber infrastructure where SC connectors are standard.

Is the WS-G5486 hot-swappable?

Yes. The WS-G5486 is a hot-swappable GBIC, allowing it to be installed or replaced quickly on supported equipment with minimal disruption.

Is this product new and covered under warranty?

Yes. This module is Cisco genuine, brand new, factory-sealed, retail-boxed, and includes the Cisco limited lifetime warranty when purchased through Chicago Computer Supply.
