IE-4010-4S24P Cisco Industrial Ethernet 4010 PoE+ Managed Switch

BRAND NEW, FACTORY-SEALED, AND BACKED BY A FULL CISCO MANUFACTURER'S WARRANTY. SUPPLIED BY CHICAGO COMPUTER SUPPLY.

Overview

The IE-4010-4S24P is a high-performance Cisco Industrial Ethernet 4010 Series managed switch built for demanding industrial access-layer deployments. It provides twenty-four Gigabit Ethernet PoE+ ports and four SFP uplinks, delivering both power and high-speed connectivity to a wide range of industrial devices.

Designed for harsh, outdoor-ready environments, this switch runs Cisco IOS Software and supports advanced security, routing, and high-availability features. It is ideal for industrial networks that require dense PoE, reliable performance, and secure IT/OT convergence.

Key Features

·         Industrial-grade managed switch with high-density PoE+ capability

·         Twenty-four Gigabit Ethernet PoE+ ports for powered industrial devices

·         Four SFP uplink ports for fiber-based aggregation and backbone connectivity

·         Cisco IOS Software-based Layer 2 and Layer 3 features

·         Designed for continuous operation in harsh and outdoor industrial environments

·         DIN rail mountable form factor for industrial cabinets and enclosures

Technical Specifications

Manufacturer: Cisco Systems
Brand: Cisco
Model: IE-4010-4S24P
Product Type: Managed Industrial Ethernet Switch
Subcategory: Network Hubs and Switches
Packaged Quantity: 1 Unit

Form Factor: DIN rail mountable
Manageable: Yes

Memory:

·         Flash: 128 MB

·         RAM: 1 GB

Ports & Interfaces:

·         24 × 10/100/1000Base-T RJ-45 (PoE+)

·         4 × SFP uplink ports

·         Console RJ-45

·         Mini-USB Type B

Switching & Performance:

·         Switching Bandwidth: 56 Gbps

·         Forwarding Bandwidth: 28 Gbps

·         MAC Address Table Size: 16K entries

Routing & Management:

·         Routing Protocols: IGMP, IGMPv2, IGMPv3, Static IPv4

·         Remote Management: CLI, HTTP, RMON, SCP, SNMP v1/v2/v3, SSH, Telnet

Security:

·         Encryption: FIPS 140-2

·         Authentication: RADIUS, TACACS

Capacity:

·         VLANs: Up to 1000

·         IGMP Groups: Up to 1000

·         NAT Translations: 128

Environmental Specifications:

·         Operating Temperature: -40°F to 167°F

·         Storage Temperature: -40°F to 185°F

·         Operating Humidity: 5–95% non-condensing

·         MTBF: 429,620 hours

Software: Cisco IOS LAN Base

Use Cases

The IE-4010-4S24P acts as an access-layer switch in industrial Ethernet networks supporting factory automation, smart infrastructure, transportation systems, utilities, oil and gas facilities, and outdoor enclosures. It powers and connects cameras, access points, sensors, and controllers at scale.

Why Choose IE-4010-4S24P

·         Delivers high-density PoE+ for large industrial device deployments

·         Supports secure IT and OT network convergence using Cisco IOS Software

·         Built for extreme temperatures and continuous industrial workloads

·         Provides fiber uplink flexibility for scalable network architectures

·         Trusted Cisco industrial platform with a full manufacturer's warranty

FAQs

What is the IE-4010-4S24P used for?

The IE-4010-4S24P is used as an industrial access switch to deliver PoE+ power and Gigabit Ethernet connectivity to large numbers of industrial devices in harsh and outdoor environments.

Does the IE-4010-4S24P support Power over Ethernet?

Yes. It includes twenty-four PoE+ Gigabit Ethernet ports, allowing it to power devices such as cameras, access points, sensors, and industrial controllers directly over Ethernet.

Is the IE-4010-4S24P suitable for harsh industrial environments?

Yes. It is for extreme temperatures, continuous operation, and outdoor or industrial enclosures where reliability and durability are critical.

What uplink options are available on this switch?

The switch includes four SFP uplink ports, providing flexible fiber connectivity for aggregation, backbone links, and long-distance industrial networking.

Does the IE-4010-4S24P include Cisco warranty coverage?

Yes. The product is brand new, factory-sealed, and includes a full Cisco manufacturer's warranty when purchased from Chicago Computer Supply.
