HP Aruba 2530-48-PoE+ Managed Switch J9778A#ABA

BRAND NEW. FACTORY SEALED. RETAIL BOXED. FULL HPE LIMITED LIFETIME WARRANTY INCLUDED. FROM CHICAGO COMPUTER SUPPLY.

Overview

Every growing network eventually reaches a point where more devices demand stable connectivity. Offices add phones. Security cameras appear in every corner. Wireless access points spread across the workspace. When that moment arrives, the access switch becomes the backbone of daily operations.

The HP Aruba 2530-48-PoE+ Managed Switch J9778A delivers reliable Layer 2 switching with integrated Power over Ethernet. It supports business networks that power multiple devices while maintaining secure, prioritized traffic. Designed for enterprise edge, SMB, and branch deployments, the switch combines stability, simple management, and long-term network scalability.

Key Features

• 48 × PoE+ Ethernet ports for powering network devices
• Fully managed Layer 2 switch for enterprise edge networks
• Traffic prioritization through advanced Quality of Service
• IPv6 support for modern networking environments
• VLAN segmentation for network organization and security
• Network monitoring through sFlow technology
• Flexible installation with rack, wall, or desktop mounting
• Multiple management options, including CLI, SNMP, and Web GUI

Technical Specifications

Brand: HP Aruba
SKU / Part Number: J9778A#ABA
Product Series: Aruba 2530
Product Model: 2530-48-PoE+
Product Type: Managed Ethernet Switch

Ports
Access Ports: 48 × PoE+ RJ-45 Ethernet ports
Expansion Slots: SFP uplink support for fiber connectivity

Network Technology
10/100Base-TX
10/100/1000Base-T

Layer Support
Layer 2 switching

PoE Support
PoE Standard: IEEE 802.3af / IEEE 802.3at
PoE Capability: Up to 30 W per port

Network Features
Flow control
DHCP support
BOOTP support
ARP support
Auto MDI/MDI-X
Port mirroring
VLAN segmentation
Traffic prioritization

Security and Protocol Support
Access Control Lists (ACL)
Multiple Spanning Tree Protocol (MSTP)
LLDP device discovery
Class of Service (CoS)
Generic Attribute Registration Protocol (GARP)

Management and Monitoring
SNMP management
Command Line Interface (CLI)
Web GUI management
Network monitoring using sFlow

Energy Efficiency
Energy Efficient Ethernet support for power savings

Physical

Form Factor: Rack-mountable, wall-mountable, or desktop
Total Network Ports: 48
Media Type Supported: Twisted Pair

Part Number: J9778A#ABA
UPC: 00641753363228

Use Cases

The Aruba 2530-48-PoE+ switch supports networks with many devices that require both power and connectivity. Offices use it to run VoIP systems, wireless access points, and security cameras without separate power adapters. Retail stores and distributed business locations deploy it to maintain stable connectivity while simplifying infrastructure management.

Why Choose HP Aruba 2530-48-PoE+ J9778A

• Forty-eight PoE+ ports to power large device deployments
• Reliable Layer 2 switching designed for enterprise edge networks
• Traffic prioritization that supports voice and critical business applications
• Network segmentation using VLAN capabilities
• Centralized monitoring through SNMP and sFlow tools
• Energy-efficient operation to reduce power consumption
• Flexible installation across rack, wall, or desktop environments
• Brand new hardware backed by a full HPE lifetime warranty from Chicago Computer Supply

FAQs

What type of switch is the Aruba J9778A?

It is a fully managed Layer 2 Ethernet switch designed for enterprise edge, branch office, and SMB networks.

How many ports does the switch provide?

The device includes forty-eight PoE+ Ethernet ports.

Does the switch support Power over Ethernet?

Yes. It supports PoE+ and can power devices such as IP phones, wireless access points, and security cameras.

Does the switch support VLAN configuration?

Yes. VLAN support allows network administrators to segment traffic and improve security.

How can the switch be managed?

Administrators can manage the device via SNMP, the command-line interface, or a web-based management interface.

Does the warranty cover the switch?

Yes. The device is brand new, factory sealed, and includes the full HPE limited lifetime warranty from Chicago Computer Supply.
