HPE X150 100G CFP2 LC LR4 10km SM Transceiver JH289A

Specifications:

• Media Type: Double Fiber Single-Mode Fiber (SMF.)
• TX Wavelength: 1310 nm.
• RX Wavelenght: 1310 nm.
• Minimum Optical Budget: 6.3 dB
• Maximum Distance: 10km
• Supported Data Rate: 103.125 to 112.2 Gbps
• Supported Applications: 100G Ethernet (103.125Gbps), OTU4 (112Gbps)
• DDM/DOM: Supported
• Temperature Range: Standard 0°-70°C
• Connectors: Double LC
• Tx Wavelength Bandwidth: 4 WDM Seperated 1310 nm Lanes (15.66 nm 1294.53 – 1310.19nm) (L0 Tx center 1295.56nm, L1 Tx center 1300.05nm, L2 Tx center 1304.58nm, L3 Tx center 1309.14nm)
• Rx Wavelength Bandwidth: 4 WDM Seperated 1310 nm Lanes (15.66 nm 1294.53 – 1310.19nm) (L0 Tx center 1295.56nm, L1 Tx center 1300.05nm, L2 Tx center 1304.58nm, L3 Tx center 1309.14nm)
• Minimum Transmitting Power: Each Lane -4.3 dBm
• Maximum Transmitting Power: Each Lane 4.5 dBm
• Receiver Sensitivity: Each Lane -10.6 dBm
• Receiver Overload: Each Lane 4.5 dBm
• Transmitter Type: EML Laser
• Receiver Type: PIN photodiode
• Power: +3.3V single power supply
• Chipset: MAXIM, MINDSPEED, SEMTECH, UX
• Compliance: 100GBASE-LR4, CE, CFP2 MSA,, Class 1 FDA and IEC60825-1 Laser Safety Compliant, IEEE 802.3ba, RoHS, SFF-8431
