HPE Aruba 3810M 24SFP+ 250W 24-Port Rack-Mountable Switch JL430A

BRAND NEW. FACTORY SEALED. RETAIL BOXED. FULL HPE WARRANTY INCLUDED. FROM CHICAGO COMPUTER SUPPLY

Overview

The HPE Aruba 3810M JL430A delivers enterprise-grade performance in a compact 1U rack-mountable design. With 24 SFP+ ports and advanced Layer 3 routing, it supports high-speed fiber connectivity for campus, branch, and aggregation deployments. If your network depends on low latency and reliable backhaul capacity, this model provides the headroom to grow.

Built for resiliency, the 3810M series supports redundant power options and hot-plug components. It integrates with Aruba management and security platforms, helping IT teams maintain visibility, enforce policy, and simplify day-to-day operations.

Key Features

• 24 × SFP+ ports for high-speed fiber connectivity
• Layer 3 routing with support for BGP and OSPF
• 160 Gbps routing and switching capacity
• 169 Gbps switching fabric bandwidth
• Redundant power supply support (1+1 option)
• Advanced management and security integration

Technical Specifications

Brand: HPE Aruba
Model / Part Number: JL430A#ABA
Series: Aruba 3810M
Device Type: Layer 3 Managed Switch
Form Factor: 1U Rack-mountable
Ports: 24 × SFP+
Routing/Switching Capacity: 160 Gbps
Switching Fabric Bandwidth: 169 Gbps
Throughput: 95.2 Mpps (64-byte packets)
Latency: 2.8 µs (1Gbps), 1.8 µs (10Gbps)
MAC Address Table: 64K entries
Routing Protocols: BGP, BGP-4, OSPFv2, OSPFv3, RIP-1, RIP-2
Remote Management: SNMP 1/2c/3, SSH-2, RMON, XRMON
Power: 250W internal power supply
Power Redundancy: Supported (1+1 with optional PSU)
Nominal Voltage: DC 12V
Height: 1.7 in
Width: 17.4 in
Depth: 17 in
Weight: 13.27 lb

Use Cases

JL430A is well-suited for enterprise aggregation layers and high-speed access deployments that rely on fiber connectivity. It supports campus cores, branch aggregation points, and data-heavy environments that require consistent 10G links. With strong routing support and a large MAC table, it handles segmented traffic and growing user counts without performance drops. Redundant power capability also makes it a dependable option for critical network segments.

Why Choose HPE Aruba 3810M JL430A

• High-density SFP+ fiber connectivity
• Layer 3 routing for scalable enterprise networks
• Strong switching capacity with low latency
• Redundant power support for improved uptime
• Backed by full HPE warranty coverage

FAQs

How many SFP+ ports does JL430A include?

It includes 24 SFP+ ports for high-speed fiber connections.

Is this switch suitable for Layer 3 routing?

Yes. It supports Layer 3 routing protocols such as OSPF and BGP.

Does it support redundant power?

Yes. It supports 1+1 power redundancy with an optional additional power supply.

What is the switching capacity?

It delivers up to 160 Gbps routing and switching capacity.

Is the unit new and covered by warranty?

Yes. It is brand new, factory-sealed, retail-boxed, and includes full HPE warranty coverage.
