HPE Aruba Instant On 1930 48G 4SFP/SFP+ Switch JL685A

BRAND NEW. FACTORY SEALED. RETAIL BOXED. FULL HPE WARRANTY INCLUDED. FROM CHICAGO COMPUTER SUPPLY

Overview

The HPE Aruba Instant On 1930 JL685A is a smart-managed Gigabit switch built for small and growing businesses that need dependable performance and simple control. It offers 48 Gigabit Ethernet ports and four SFP/SFP+ uplinks, delivering strong connectivity for bandwidth-intensive applications such as video conferencing, cloud collaboration, and file sharing.

Designed to integrate seamlessly with Aruba Instant On access points, this Layer 2+ switch supports centralized cloud management. IT teams can configure, monitor, and manage the network using the Instant On mobile app or web portal. With enterprise-grade reliability and zero subscription requirements, it delivers value without complexity.

Key Features

• 48 × 10/100/1000 Gigabit Ethernet ports
• 4 × 1G/10G SFP/SFP+ uplink ports for fiber connectivity
• 176 Gbps switching capacity for smooth data flow
• Smart-managed Layer 2+ functionality with static routing
• Cloud-based, mobile app, and local web management options
• Limited lifetime warranty with dedicated support

Technical Specifications

Brand: HPE Aruba
Model: Instant On 1930 48G 4SFP/SFP+
Part Number: JL685A#ABA
Ports: 48 × Gigabit RJ-45 ports
Uplinks: 4 × 1G/10G SFP/SFP+
Switching Capacity: 176 Gbps
Throughput: Up to 130.95 Mpps
Processor: ARM Cortex-A9 @ 800 MHz
Memory: 512 MB SDRAM
Flash: 256 MB
Packet Buffer: 1.5 MB
Power Consumption: 36.9 W maximum
Input Voltage: 100–240 VAC
Form Factor: Rack-mountable
Weight: 6.91 lb
Management: Aruba Instant On Portal, Web GUI, SNMP

Use Cases

The Aruba JL685A switch is ideal for offices, retail stores, hospitality environments, and growing startups that need stable wired connectivity. It supports high-speed links to servers and uplinks to core switches through SFP+ ports. Businesses use it to power structured cabling networks that support collaboration tools, cloud services, and connected devices. It also integrates easily with Aruba wireless solutions to deliver unified wired and wireless networking.

Why Choose Aruba JL685A

• Delivers reliable Gigabit performance for business networks
• Supports high-speed fiber uplinks for scalable expansion
• Enables centralized cloud-based management
• Provides enterprise-level performance without subscription fees
• Backed by a limited lifetime warranty

FAQs

How many ports does the Aruba JL685A switch provide?

It includes 48 Gigabit Ethernet ports and 4 SFP/SFP+ uplink ports.

Is this switch suitable for small and growing businesses?

Yes. It best supports SMB networks with reliable and scalable performance.

Does it support cloud management?

Yes. You can manage it through the Aruba Instant On mobile app, cloud portal, or local web interface.

What is the switching capacity of this model?

The switch offers 176 Gbps switching capacity for smooth and efficient network traffic handling.

Does this model include PoE functionality?

No. The JL685A is a non-PoE model designed for standard Gigabit connectivity.
