HPE 400GB SAS 12G Write Intensive SFF 2.5 Inch SC Solid State Drive P09098-B21

BRAND NEW FACTORY SEALED & RETAIL BOXED WITH THE FULL HPE WARRANTY!!!

Overview

The HPE 400GB SAS 12G Write Intensive SFF 2.5 Inch SC Solid State Drive P09098-B21 is an enterprise-class SSD designed for write-intensive application workloads requiring high random read and write IOPS performance. With 400GB storage capacity, a SAS 12Gb/s interface, and 10 DWPD endurance, this SSD is built for demanding enterprise server environments.

The P09098-B21 uses MLC NAND Flash memory and delivers an external transfer rate of 1.2 GBps, with internal data rates of up to 1,095 MBps read and 1,015 MBps write. It provides up to 210,000 IOPS maximum 4KB random read and 120,000 IOPS maximum 4KB random write, making it suitable for applications with demanding read and write requirements.

The SSD features an HPE Smart Carrier, hot-plug capability, and Digitally Signed Firmware. It also supports HPE Smart WearGauge compatibility in management tools, helping administrators monitor SSD lifespan. HPE SSDs are backed by more than 3.35 million hours of testing and qualification to support reliable enterprise operation.

Key Features

• 400GB storage capacity
• SAS 12Gb/s interface
• Write Intensive workload classification
• 10 DWPD endurance
• 7,000TB SSD endurance
• 7,000TB lifetime writes
• 140,000 IOPS 4KB random read at Q=16
• Up to 210,000 IOPS 4KB maximum random read at Q32
• 120,000 IOPS 4KB random write at Q=16
• 120,000 IOPS maximum 4KB random write at Q16
• 1.2 GBps external transfer rate
• 1,095 MBps internal read rate
• 1,015 MBps internal write rate
• MLC NAND Flash memory
• HPE Smart Carrier included
• Hot-plug capability
• 2.5-inch SFF form factor
• Digitally Signed Firmware
• HPE Smart WearGauge compatibility
• Backed by the full HPE warranty

Technical Specifications

• Brand: HPE
• Manufacturer: Hewlett Packard Enterprise
• Manufacturer Part Number (MPN): P09098-B21
• Device Type: Solid State Drive - Hot-Swap
• Storage Capacity: 400GB
• NAND Flash Memory Type: Multi-level Cell (MLC)
• Form Factor: 2.5-inch SFF
• Interface: SAS 12Gb/s
• Interfaces: 1 x SAS 12Gbps
• Features: Digitally Signed Firmware
• Workload Type: Write Intensive
• Carrier Type: Smart Carrier (SC)
• Plug Type: Hot Plug
• Bundled With: HPE Smart Carrier
• Drive Writes Per Day (DWPD): 10 DWPD
• SSD Endurance: 7,000TB
• Lifetime Writes: 7,000TB
• Drive Transfer Rate: 1.2 GBps external
• Internal Data Rate: 1,095 MBps read / 1,015 MBps write
• Compatible Bay: 2.5-inch SFF
• Height: 8.75 inches
• Width: 7.25 inches
• Depth: 5.5 inches
• Weight: 1.1 lb

Performance Specifications

• External Transfer Rate: 1.2 GBps
• Internal Read Rate: 1,095 MBps
• Internal Write Rate: 1,015 MBps
• 4KB Random Read IOPS: 140,000 IOPS at Q=16
• Maximum 4KB Random Read IOPS: 210,000 IOPS at Q32
• 4KB Random Write IOPS: 120,000 IOPS at Q=16
• Maximum 4KB Random Write IOPS: 120,000 IOPS at Q16
• Endurance: 10 DWPD
• SSD Endurance: 7,000TB
• Lifetime Writes: 7,000TB
• Interface: SAS 12Gb/s

The P09098-B21 is optimized for Write Intensive workloads, providing high random read and write performance for applications with frequent and demanding storage operations.

Enterprise Features

• HPE Smart Carrier provides a carrier solution for supported HPE server configurations.
• Digitally Signed Firmware helps provide assurance that the drive firmware comes from a trusted source.
• HPE Smart WearGauge compatibility allows supported management tools to monitor SSD lifespan.
• 10 DWPD endurance supports demanding applications with frequent write operations.
• MLC NAND Flash memory provides the storage media for this enterprise SSD.
• Hot-plug capability allows convenient installation and replacement in supported server configurations.
• HPE SSDs are backed by more than 3.35 million hours of testing and qualification for enterprise reliability.

Physical Specifications

• Form Factor: 2.5-inch SFF
• Compatible Bay: 2.5-inch SFF
• Carrier Type: Smart Carrier (SC)
• Bundled With: HPE Smart Carrier
• Installation: Hot Plug
• Height: 8.75 inches
• Width: 7.25 inches
• Depth: 5.5 inches
• Weight: 1.1 lb

Power Consumption

• Maximum: 5.74W
• Random Read: 5.22W
• Random Write: 5.22W
• Sequential Read: 4.07W
• Sequential Write: 5.74W
• Random Read/Write: 5.22W

Compatible Platforms

The HPE P09098-B21 is designed for supported HPE enterprise server configurations featuring a compatible 2.5-inch SFF SAS drive bay and SAS 12Gb/s connectivity.

The exact compatible server models are not provided in the supplied specifications. Before installation, verify the specific HPE server model, generation, drive cage, storage controller, and supported SAS SSD configuration.

Ideal Applications

The HPE P09098-B21 400GB Write Intensive SSD is suitable for:

• Write-intensive enterprise applications
• Data-intensive application workloads
• High-transaction database environments
• Virtualized server environments
• Enterprise application hosting
• Applications requiring high random read and write IOPS
• Workloads requiring high SSD endurance
• Server storage platforms
• Supported HPE enterprise server configurations

Why Choose HPE P09098-B21

The HPE P09098-B21 combines 400GB storage capacity, SAS 12Gb/s connectivity, and high-performance 140,000 IOPS random read and 120,000 IOPS random write performance in a compact 2.5-inch SFF enterprise SSD.

With up to 210,000 IOPS maximum 4KB random read, 10 DWPD endurance, and 7,000TB SSD endurance, this drive is designed for demanding workloads with frequent write operations. The combination of HPE Smart Carrier, Digitally Signed Firmware, Smart WearGauge compatibility, and hot-plug support makes it a strong storage solution for compatible HPE server environments.

Compatibility

• Storage Capacity: 400GB
• Interface: SAS 12Gb/s
• Interface Connection: 1 x SAS 12Gbps
• Form Factor: 2.5-inch SFF
• Compatible Bay: 2.5-inch SFF
• Carrier: HPE Smart Carrier
• Carrier Type: Smart Carrier (SC)
• Installation: Hot Plug
• Workload Type: Write Intensive
• Endurance: 10 DWPD
• SSD Endurance: 7,000TB
• Supported Device: Server
• Compatibility: Supported HPE enterprise server configurations with compatible 2.5-inch SFF SAS drive bays

FAQs

What is the storage capacity of the HPE P09098-B21?
The HPE P09098-B21 provides 400GB of storage capacity and is designed for demanding enterprise server workloads.

What interface does the HPE P09098-B21 use?
The P09098-B21 uses a SAS 12Gb/s interface, with 1 x SAS 12Gbps connection.

What type of workload is the P09098-B21 designed for?
The P09098-B21 is a Write Intensive (WI) SSD, designed for applications requiring high levels of random read and write IOPS and high write endurance.

What are the random read and write IOPS of this SSD?
The drive provides 140,000 IOPS 4KB random read at Q=16 and 120,000 IOPS 4KB random write at Q=16. Maximum performance is specified at 210,000 IOPS random read at Q32 and 120,000 IOPS random write at Q16.

What is the endurance rating of the HPE P09098-B21?
The P09098-B21 has an endurance rating of 10 DWPD and a specified 7,000TB SSD endurance.

Does the HPE P09098-B21 include a Smart Carrier?
Yes. The P09098-B21 includes an HPE Smart Carrier and is designed for a compatible 2.5-inch SFF bay with hot-plug support.
