HPE 1.92TB NVMe x4 Lanes Read Intensive SSD P13691-B21

BRAND NEW WITH THE FULL HPE WARRANTY!!!

Overview

The HPE P13691-B21 1.92TB NVMe x4 Lanes Read Intensive Solid State Drive is an enterprise-grade storage solution designed to deliver high-speed performance for demanding server environments. Using a PCI Express x4 (NVMe) interface and an M.2 22110 form factor, this SSD provides fast data access, low latency, and efficient storage performance for compatible HPE server platforms.

With 1.92TB of storage capacity, the P13691-B21 is designed for read-intensive workloads where fast and consistent data retrieval is important. Its Multi-Level Cell (MLC) NAND flash technology, high random read IOPS, and PCIe NVMe connectivity make it suitable for applications such as virtualization, databases, enterprise applications, server boot environments, and data-intensive workloads.

The drive delivers up to 145,000 4KB random read IOPS and 54,000 4KB random write IOPS, with maximum random read performance reaching 425,000 IOPS. It also provides an internal read data rate of up to 3300 MBps, helping reduce storage bottlenecks in compatible enterprise systems.

The SSD includes Digitally Signed Firmware, helping maintain firmware integrity and providing an additional layer of security for enterprise storage environments. With an endurance rating of 4,765 TB and 1.36 DWPD, it is designed for reliable operation in read-intensive server workloads.

Key Features

• Genuine HPE enterprise solid state drive
• 1.92TB storage capacity
• Read Intensive (RI) workload design
• PCI Express x4 (NVMe) interface
• PCIe NVMe high-speed storage connectivity
• M.2 22110 form factor
• Multi-Level Cell (MLC) NAND flash memory
• Up to 3300 MBps internal read data rate
• Up to 1250 MBps internal write data rate
• Up to 145,000 4KB random read IOPS
• Up to 54,000 4KB random write IOPS
• Up to 425,000 maximum 4KB random read IOPS
• Up to 54,500 maximum 4KB random write IOPS
• 1.36 Drive Writes Per Day (DWPD)
• 4,765 TB SSD endurance
• Digitally Signed Firmware
• Low average latency of 0.028 millisecond
• Designed for compatible enterprise server environments
• Brand new with full HPE warranty

Technical Specifications

• Manufacturer: Hewlett-Packard
• Brand: HPE
• Product Line: HPE Read Intensive
• Part Number: P13691-B21
• Product Type: Solid State Drive
• Workload Type: Read Intensive
• Capacity: 1.92 TB
• Hard Drive Type: Internal hard drive
• Storage Interface: PCI Express x4 (NVMe)
• Interface: PCI Express x4 (NVMe)
• Interfaces: 1 x PCI Express x4 (NVMe) - M.2 Card
• Form Factor: M.2 22110
• Form Factor (Metric): M.2 22110
• Form Factor (Short): M.2
• NAND Flash Memory Type: Multi-Level Cell (MLC)
• Compatible Bay: M.2 22110
• Features: Digitally Signed Firmware
• Average Latency: 0.028 millisecond
• Drive Writes Per Day (DWPD): 1.36
• SSD Endurance: 4,765 TB

Performance Specifications

The HPE P13691-B21 is designed to provide high-performance storage for read-intensive enterprise applications.

• Internal Data Rate: 3300 MBps
• Internal Data Rate (Write): 1250 MBps
• 4KB Random Read: 145,000 IOPS
• 4KB Random Write: 54,000 IOPS
• Maximum 4KB Random Read: 425,000 IOPS
• Maximum 4KB Random Write: 54,500 IOPS
• Average Latency: 0.028 millisecond
• Drive Writes Per Day: 1.36 DWPD
• SSD Endurance: 4,765 TB

The high random read performance and PCIe x4 NVMe interface make the drive suitable for workloads that require rapid access to frequently used data.

Physical Specifications

The P13691-B21 uses an M.2 22110 form factor, making it different from standard 2.5-inch SFF enterprise SSDs. Its compact M.2 design allows it to be installed in compatible server systems that provide an M.2 22110 NVMe storage slot.

• Form Factor: M.2 22110
• Form Factor Type: M.2
• Compatible Bay: M.2 22110
• Height: 0.1 inch
• Interface Connector: PCI Express x4 (NVMe) - M.2 Card

Because this is an M.2 22110 NVMe drive, compatibility with the server's physical slot, PCIe lanes, backplane, and firmware should be confirmed before installation.

Power Consumption

The SSD is designed to provide efficient enterprise storage performance with the following listed power consumption figures:

• Idle: 2.42 Watt
• Random Read: 6.27 Watt
• Random Write: 6.27 Watt
• Sequential Read: 6.8 Watt
• Sequential Write: 6.55 Watt
• Maximum: 6.8 Watt

Enterprise Features

The HPE P13691-B21 includes Digitally Signed Firmware, which helps ensure that the drive firmware comes from a trusted source. This is an important feature for enterprise environments where firmware integrity and storage security are priorities.

The drive also provides a high 1.36 DWPD endurance rating and 4,765 TB total SSD endurance, making it suitable for sustained enterprise read-intensive workloads.

Installation & Compatibility

The P13691-B21 uses a PCI Express x4 NVMe interface with an M.2 22110 physical form factor. It should only be installed in HPE server configurations that specifically support M.2 22110 NVMe storage with the required PCIe connectivity.

Before purchasing, verify your exact HPE server model and configuration, including the M.2 slot, supported drive type, PCIe lane availability, server firmware, and storage configuration.

Ideal Applications

The HPE P13691-B21 is suitable for:

• Enterprise server storage
• Read-intensive workloads
• Database applications
• Virtualization environments
• Enterprise application servers
• Server boot and operating system storage
• Data-intensive applications
• Frequently accessed data
• Read caching workloads
• Data center infrastructure
• High-performance server environments
• Compatible HPE server deployments

Why Choose the HPE P13691-B21

The HPE P13691-B21 combines 1.92TB capacity, PCIe x4 NVMe connectivity, M.2 22110 form factor, MLC NAND flash, high random read performance, and enterprise endurance in a compact storage solution.

Its 3300 MBps internal read data rate, up to 145,000 4KB random read IOPS, and up to 425,000 maximum random read IOPS make it well suited to read-intensive applications that require fast data access.

The combination of 1.36 DWPD endurance, 4,765 TB SSD endurance, low latency, and Digitally Signed Firmware makes this drive a strong option for supported enterprise server environments.

FAQs

What is the storage capacity of the HPE P13691-B21?
The HPE P13691-B21 provides 1.92TB of solid-state storage capacity.

What interface does the HPE P13691-B21 use?
The drive uses a PCI Express x4 (NVMe) interface through an M.2 connection.

What is the form factor of the P13691-B21?
The HPE P13691-B21 uses an M.2 22110 form factor and is designed for compatible server systems supporting this physical drive format.

What are the random read and write performance figures?
The drive provides up to 145,000 4KB random read IOPS and 54,000 4KB random write IOPS. Maximum random read performance is listed at 425,000 IOPS.

What is the endurance rating of the HPE P13691-B21?
The SSD has an endurance rating of 1.36 DWPD and a listed SSD endurance of 4,765 TB.

What type of workloads is the P13691-B21 designed for?
The P13691-B21 is an HPE Read Intensive SSD designed for enterprise workloads that require fast and frequent data reads, including databases, virtualization, server boot environments, read caching, and other data-intensive applications.
