HPE ProLiant DL320 Gen11 12-Core 2.0GHz 500W Rack-Mountable Server – P57687-B21

BRAND NEW FACTORY SEALED & RETAIL BOXED WITH THE FULL HPE WARRANTY!!!

The HPE ProLiant DL320 Gen11 P57687-B21 is a compact and high-performance 1U rack server designed for modern data center workloads, virtualization, edge computing, and software-defined infrastructure. Powered by the 4th Generation Intel Xeon Scalable processor platform, the DL320 Gen11 delivers exceptional compute power, enhanced security, and next-generation expandability in a space-efficient design.

Built to support demanding business applications, the server features DDR5 Smart Memory, PCIe Gen5 expansion, advanced storage flexibility, and integrated HPE iLO 6 management for secure remote administration and streamlined lifecycle management.

Key Features

• Intel Xeon Silver 4410Y 12-core processor
• HPE DDR5 Smart Memory support
• Compact 1U rack-mountable design
• PCIe Gen5 and OCP 3.0 expansion
• Supports up to 8 SFF SAS/SATA/NVMe drives
• HPE MR408i-o Gen11 storage controller
• Embedded dual-port 1GbE networking
• HPE iLO 6 server management
• Advanced enterprise-grade security features
• 500W Flex Slot Platinum hot-plug power supply

Specifications

General

• Brand: HPE
• Product Line: ProLiant DL320 Gen11
• Product ID: P57687-B21
• Form Factor: 1U Rack Server

Processor

• Processor Type: Intel Xeon Silver 4410Y
• Processor Cores: 12-core
• Processor Speed: 2.0 GHz
• Processor Cache: 30 MB L3
• Processors Included: 1

Memory

• Memory Type: HPE DDR5 Smart Memory
• DIMM Capacity Included: 16 GB
• Memory Speed: Up to 4800 MT/s
• Maximum Memory Support: Up to 2 TB DDR5
• DIMM Slots: 16 DIMMs per processor

Storage

• Drive Support: Up to 8 SFF SAS/SATA/NVMe drives
• Included Drives: None
• Boot Support: RAID1 NVMe M.2 boot options
• Optical Drive Support: Optional SATA DVD-RW or USB DVD-RW

Storage Controller

Controller: HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller

Networking

Network Controller: HPE embedded 2-port 1GbE Ethernet adapter

Expansion

• Expansion Slots:
  • One PCIe Gen5 slot
  • One OCP 3.0 PCIe Gen5 slot

Cooling

System Fans: Five standard fans

Power Supply

Power Supply Type: HPE 500W Flex Slot Platinum Hot Plug Power Supply

Security Features

• UEFI Secure Boot
• Secure Start support
• Intel Software Guard Extensions (SGX)
• Immutable Silicon Root of Trust
• Optional TPM support
• Chassis intrusion detection
• Bezel locking kits
• Advanced iLO security modes

Ideal Workloads

• Virtualization
• Data management
• Edge AI
• Software-defined storage
• Software-defined compute
• Content Delivery Network (CDN)
• Intelligent Video Analytics (IVA)
• Virtual Desktop Infrastructure (VDI)
• General enterprise computing
• Data collection and analytics

Why Choose HPE DL320 Gen11?

The HPE ProLiant DL320 Gen11 combines next-generation Intel Xeon performance with advanced DDR5 memory, PCIe Gen5 connectivity, and enterprise-class security in a compact 1U design. Its balance of performance, scalability, and efficiency makes it ideal for businesses modernizing their IT infrastructure while maximizing rack space and operational efficiency.

Frequently Asked Questions

Is this server brand new?
Yes, this server is brand new factory sealed and includes the full HPE warranty.

What processor is installed?
The server includes one Intel Xeon Silver 4410Y 12-core processor.

Does the server include hard drives?
No, hard drives are not included.

What type of drives are supported?
The server supports SAS, SATA, and NVMe SFF drives.

What remote management is included?
The server includes HPE iLO 6 Standard with Intelligent Provisioning.

Does the server support DDR5 memory?
Yes, the DL320 Gen11 supports HPE DDR5 Smart Memory up to 4800 MT/s.
