HPE ProLiant Compute DL360 Gen12 6530P Server P89997-005

BRAND NEW WITH FULL HPE WARRANTY!!!

The HPE ProLiant Compute DL360 Gen12 6530P 1P 2x32GB-R 8SFF NS204i-u v2 MR408i-o 2x1000W PS NA Server (P89997-005) is a high-performance enterprise rack server engineered for compute-intensive workloads across virtualization, databases, analytics, and hybrid cloud environments. At its core is a single Intel® Xeon® 6530P processor with 32 cores running at 2.30 GHz (144 MB L3 cache) paired with 64 GB of DDR5 registered ECC Smart Memory, delivering robust processing power and memory bandwidth for demanding business applications and scalable multi-tenant systems.

Designed in a 1U rack-optimized chassis, this configuration includes an HPE NS204i-u v2 480 GB NVMe boot-optimized storage device and supports up to eight hot-swap 2.5″ drives for flexible future expansion. The integrated HPE MR408i-o Gen11 RAID controller with 4 GB cache enhances data resiliency and performance across SAS and NVMe media, while dual 1000 W Flex Slot Titanium hot-plug power supplies provide redundant power for high availability. Advanced remote management is delivered through HPE Integrated Lights-Out 7 (iLO7) with Intelligent Provisioning and HPE OneView Standard support.

Key Features – HPE ProLiant Compute DL360 Gen12 6530P – P89997-005

• Processor:
 o Intel® Xeon® 6530P, 32 cores, 2.30 GHz, 144 MB L3 cache

• Memory:
 o 64 GB (2 × 32 GB) DDR5 Registered ECC Smart Memory

• Storage:
 o HPE NS204i-u v2 480 GB NVMe boot-optimized device
 o Support for 8 × hot-swap 2.5″ drive bays

• Controller (if applicable):
 o HPE MR408i-o Gen11 x8 Lanes 4 GB Cache OCP SPDM Storage Controller

• Networking / Ports:
 o Broadcom BCM5719 4-port 1 GbE BASE-T OCP adapter
 o USB 3.x ports, VGA, Dedicated iLO7 port

• Power & Cooling:
 o 2 × HPE 1000 W Flex Slot Titanium Hot-Plug Power Supplies
 o 7 × high-performance hot-plug fans

• Management:
 o HPE Integrated Lights-Out 7 (iLO7) Standard, optional iLO7 Advanced & OneView Advanced

• Security (if applicable):
 o UEFI Secure Boot, Immutable Silicon Root of Trust

• Form Factor:
 o 1U rack server

Technical Specifications

• Processor Type: Intel® Xeon® 6530P (32-core)
• Chipset / Platform: HPE ProLiant Gen12 architecture
• Memory Technology: DDR5 Registered ECC Smart Memory
• Storage Interface: NVMe / SAS / SATA backplane
• RAID Support: HPE MR408i-o RAID (0,1,5,6,10,50,60)
• Expansion Slots: Up to 3 PCIe Gen5 ×16 lanes & 2 OCP3.0 slots
• Networking: Integrated 4-port 1 GbE OCP adapter; optional NICs via OCP/PCIe
• I/O Ports: USB 3.x, VGA, Dedicated iLO7 port
• Operating System Compatibility: Microsoft Windows Server, VMware ESXi, Red Hat Enterprise Linux, SUSE Linux Enterprise Server

Physical Specifications

• Form Factor:
 o 1U Rack server

• Weight:
 o 11.5 kg
 o 25.35 lbs
(Verified for similar DL360 Gen12 configurations; server compute chassis standardizes 1U weight)

• Dimensions (H × W × D):
 o 43.4 mm × 434.6 mm × 772.8 mm
 o 1.71″ × 17.11″ × 30.42″
(Standard 1U industry rack server dimensions from DL360 Gen12 chassis)

• Rack Compatibility:
 o Standard 19″ rack, occupies 1U height

Ideal For

• Virtualized infrastructure hosts and hypervisor clusters
• High-performance database servers
• Application tier and middleware workloads
• Hybrid cloud and edge computing deployments
• Enterprise business workloads requiring efficient density in 1U

Warranty & Support

• Standard manufacturer warranty: 3 years parts, 3 years labor, 3 years onsite support (3/3/3).
• Support contract compatibility: HPE Care Pack, HPE Proactive Care, HPE Foundation Care, HPE OneView and GreenLake management options.

FAQs – HPE ProLiant Compute DL360 Gen12 6530P – P89997-005

Q1: Can this server’s processor be upgraded?
A1: Yes. The DL360 Gen12 supports compatible Intel® Xeon® 6500/6700 series processors subject to TDP and platform power limits.

Q2: What storage does this configuration include?
A2: This SKU includes an HPE NS204i-u v2 480 GB NVMe boot device; additional drives can be installed in the eight hot-swap 2.5″ bays.

Q3: Does the server support redundant power?
A3: Yes. Dual Flex Slot Titanium hot-plug power supplies provide redundancy to maximize uptime.

Q4: What remote management tools are available?
A4: HPE iLO7 Standard is included; optional Advanced and OneView upgrades are available for enhanced automation.

Q5: Is this suitable for enterprise virtualization?
A5: Yes. With 32 cores and scalable memory, it fits virtualization, cloud, and dense compute environments.

Q6: What rack height does this server occupy?
A6: This server is designed for a standard 19″ rack and occupies 1U of vertical space.
