HPE ProLiant Compute DL380 Gen12 6530P 1P 2x32GB-R 8SFF Server P90005-005

BRAND NEW WITH FULL HPE WARRANTY!!!

The P90005-005 – HPE ProLiant Compute DL380 Gen12 6530P 1P 2x32GB-R 8SFF NS204i-u v2 MR408i-o 2x1000W PS NA Server is a next-generation enterprise rack server engineered for demanding data center workloads, virtualization clusters, and hybrid cloud infrastructures. Powered by a single Intel® Xeon® 6530P processor with 32 cores at 2.30 GHz and supported by 64 GB of DDR5 HPE Smart Memory, this configuration delivers a high core count and memory bandwidth ideal for compute-intensive business applications, large-scale virtualization, and high-throughput analytics.

Built on the scalable 2U rack form factor, the DL380 Gen12 platform combines dense compute, flexible storage, and advanced services. It includes an HPE NS204i-u v2 480 GB NVMe boot-optimized device plus support for eight hot-swap 2.5″ drive bays, enabling agile storage configurations for mission-critical data and large datasets. Dual 1,000 W Flex Slot Titanium hot-plug power supplies ensure redundant power delivery for high availability, and HPE iLO7 remote management simplifies provisioning, monitoring, and maintenance across distributed server environments.

Key Features – HPE ProLiant Compute DL380 Gen12 6530P – P90005-005

• Processor:
 o Intel® Xeon® 6530P, 32 cores, 2.30 GHz base frequency, 144 MB L3 cache
• Memory:
 o 64 GB (2 × 32 GB) DDR5 Registered ECC Smart Memory
• Storage:
 o Supports 8 × 2.5″ hot-swap SAS/SATA/NVMe bays
 o Includes HPE NS204i-u v2 480 GB NVMe boot-optimized device
• Controller (if applicable):
 o HPE MR408i-o Gen11 x8 Lanes 4 GB Cache OCP Storage Controller
• Networking / Ports:
 o Broadcom BCM5719 4-port 1 GbE BASE-T OCP adapter
 o USB 3.x, VGA, Dedicated iLO port
• Power & Cooling:
 o Dual HPE 1000 W Flex Slot Titanium Hot-Plug Power Supplies
 o Six high-performance hot-swap fans
• Management:
 o HPE Integrated Lights-Out (iLO) Standard; optional iLO Advanced and OneView
• Security (if applicable):
 o TPM 2.0, Silicon Root of Trust, Secure Boot
• Form Factor:
 o 2U rack server

Technical Specifications

• Processor Type: Intel® Xeon® 6530P, 32-core, 2.30 GHz
• Chipset / Platform: HPE ProLiant Gen12 architecture
• Memory Technology: DDR5 Registered ECC Smart Memory
• Storage Interface: SAS/SATA/NVMe (via backplane)
• RAID Support: HPE MR408i-o RAID support (0,1,5,6,10,50,60)
• Expansion Slots: Up to 8 PCIe Gen5 and 2 OCP 3.0 slots
• Networking: Integrated Broadcom 1 GbE (OCP); optional FlexibleLOM/PCIe NICs
• I/O Ports: USB 3.x, VGA, iLO management port
• Operating System Compatibility: Supports Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi (HPE validated configurations recommended)

Physical Specifications

• Form Factor:
 o 2U rack-mount server

• Weight:
 o 18.0 kg
 o 39.68 lbs

• Dimensions (H × W × D):
 o 87.5 mm × 448 mm × 727 mm
 o 3.45″ × 17.64″ × 28.62″

• Rack Compatibility:
 o Standard 19″ rack, occupies 2U height

Ideal For

• Virtualized server clusters and hypervisor hosts
• Enterprise databases and analytics servers
• Hybrid cloud and edge computing workloads
• High-availability applications with redundant hardware
• Scalable storage and compute infrastructures

Warranty & Support

• Standard manufacturer warranty: 3 years parts, 3 years labor, 3 years onsite support
• Support contract compatibility: HPE Care Pack, Proactive Care, Foundation Care, and extended HPE service offerings

FAQs – HPE ProLiant Compute DL380 Gen12 6530P – P90005-005

Q1: Can I upgrade the processor?
A1: Yes. The DL380 Gen12 supports installation of compatible Intel® Xeon® 6500/6700 Series processors for expanded performance within platform thermal limits.

Q2: How much memory can this server support?
A2: When fully populated, the platform supports up to 8 TB of DDR5 HPE Smart Memory across available DIMM slots.

Q3: Are storage drives included with this SKU?
A3: This configuration includes one NS204i-u v2 480 GB NVMe boot device; additional drives may be added to the 8 hot-swap 2.5″ bays.

Q4: Does this model support redundant power?
A4: Yes. Dual 1000 W Flex Slot hot-plug power supplies provide power redundancy and support high availability.

Q5: Is remote management available?
A5: Yes. HPE iLO7 is integrated for secure remote monitoring, configuration, and firmware management.

Q6: What rack size does this server fit?
A6: This server is designed for installation in a standard 19″ rack and occupies 2U of rack height.
